Laser Red - 600 - 1000
- Laser diode with analogue modul;ated PSU
- M2 factor : <20
- Beam divergence, full angle : <3.0 mrad
- Beam diameter at the aperture : ~6.0mm
- Polarization ratio : >50:1
- Power stability (rms, over 4 hours) : < 5%
- Warm - Up time : <5 min
- Beam height from base : 15mm
- Poin stability after warm-up (mrad) : <0.05

Laser Green - 300 - 3000
- Laser diode with analogue modul;ated PSU. output power : ca.
300-3000mW/532nm
- Power stability (rms, over 4 hours) : < 5%
- Warm - Up time : <5 min
- M2 factor : <1.2
- Beam divergence, full angle : <1.5 mrad
- Beam diameter at the aperture : ~2.0mm
- Beam height from base : 24.8mm
- Spectral linewidth : <0.1nm
- Polarization ratio : >100:1(0 or 90 degree)
* Operating mode : CW
* Operating temperature : 10 - 350 C
* Expected lifetime : 10000 hours
* Power supply : 110V ~ 220V, 50/60 Hz
* Analogue modulation : 10 Khz

Laser Red - 600 - 1000
- Net weight of laser head : ca. 0.4kg
- Dimensions of laser head (mm) : 83 x 30 x 30
- Dimensions (mm) : 106 x 47 x 38 (L x W x H)

Red-600/650
* output guaranteed 500mW/650nm
* output typical 600mW/650nm
Red-600/635
* output guaranteed 500mW/635nm
* output typical 600mW/635nm
Red-1000/635
* output guaranteed 900mW/635nm
* output typical 1000mW/635nm

Laser Green - 300 - 3000
- Net weight of laser head : ca. 0.645kg
- Dimensions of laser head (mm) : 140.8 x 73 x 46.2
- Dimensions (mm) : 135 x 130 x 61 (L x W x H)
